Tubular High Temperature Sterilizer
Wide Use of Tubular High Temperature Sterilizer
Biopharmaceutical Industry
Sterilizes materials such as oral liquids and enzymes, complying with GMP standards to ensure sterility, and reducing material denaturation through short-time high-temperature treatment.
Food & Beverage Industry
Used for fluid materials like fruit juice, dairy products and sauces to kill microorganisms for preservation, while adapting to different products to retain nutrients or maintain properties.
Daily Chemical & Cosmetics Industry
Sterilizes products like toner and shampoo, removing microorganisms in raw materials to meet safety standards and avoid deterioration or odor during storage.
Product Features
Efficient Sterilization & Quality Preservation
UHT treatment (3–5s) eliminates 99.999% of microorganisms while maximizing nutrient and flavor retention, ideal for UHT milk, fresh juice, etc.
Wide Material Adaptability
Handles high-viscosity materials, fiber/particle-containing materials ,and high-acidity/corrosive materials across multiple industries.
Energy-saving & Economical
With heat exchange technology, heat recovery rate exceeds 90%, reducing steam consumption by 30–50%. Compact structure，durable materials, and lower long-term costs.
Automation & Intelligent Control
Integrated PLC + touch screen controls monitor temperature, pressure, and flow in real time for full automation. Supports parameter preset, data storage/traceability; some models have self-cleaning/reverse cleaning functions.
Hygiene & Safety Design
Sanitary quick-clamp connections and dead-corner-free polishing; equipped with double mechanical seals + barrier fluid seal , sterile breather, pressure protection, and over-temperature alarm for sterile production and safety.
Work Principle
- Preheating: Material is pumped to the preheating section, exchanging heat with sterilized hot material to 50–70℃ for energy recovery.
- Heating: Preheated material rapidly reaches the target sterilization temperature (e.g., 135℃) via steam, hot water, or electric heating.
- Heat Preservation: Material stays in the heat preservation tube for 3–5 seconds to completely kill microorganisms (including heat-resistant spores), with pressure control to prevent flash evaporation.
- Cooling: Sterilized material first exchanges heat with cold material (heat recovery rate >90%), then cools to filling temperature (≤40℃) via cooling water, with closed pipelines to avoid recontamination.
- CIP/SIP: After production, the equipment automatically performs online cleaning and sterilization.
